Folding lifter wings
reduce transport width for the road
12 rowsAt 22-inch spacing
3.5 tonTank capacity
250 hpGearbox rating
17' 8"Transport width, folded
Overview
Alloway designed its exclusive folding harvester for easy transportation to and from the field, easy maintenance and cleaning, and convenient storage. Twelve-row folding lifter wings bring a full working width down for the road, and walking tandem tires span irregular field terrain for a smooth, level ride. Available with twin 42″ scrub elevator, the largest elevator in the industry. Built in Fargo, North Dakota and supported through the Alloway dealer network.
Why growers pick it
- Folding lifter wings: reduce transport width for the road
- Walking tandem tires: span irregular terrain for a smooth, level ride; wheels match row spacing
- Steerable walking tandems: industry exclusive, for uniform lifter wheel depth
- Steep angled struts: exceptional view of lifter wheels, less trash build-up
Sizes & specs
| FH12R22 | |
|---|---|
| Row configuration | 12 rows at 22 in spacing |
| Transport width | 17' 8" |
| Operation width | 23' 9" |
| Overall length | 27' 6" |
| Transport height | 13' 10" |
| Gearbox | 250 hp |
| Tank capacity | 3.5 tons |
| Belt elevator chain | Dual 42 in |
| Empty weight | 35,000 lbs |
| Tractor PTO speed | 1000 RPM |
FH12R22
Row configuration
12 rows at 22 in spacing
Transport width
17' 8"
Operation width
23' 9"
Overall length
27' 6"
Transport height
13' 10"
Gearbox
250 hp
Tank capacity
3.5 tons
Belt elevator chain
Dual 42 in
Empty weight
35,000 lbs
Tractor PTO speed
1000 RPM
Features & options
Walking tandem tires
span irregular terrain for a smooth, level ride; wheels match row spacing
Steerable walking tandems
industry exclusive, for uniform lifter wheel depth
Steep angled struts
exceptional view of lifter wheels, less trash build-up
Hinged front barrier bracket
lets material in, not out
3-way gearboxes distribute loads
4B power band dual drive
Twin 42" elevator chains
highest capacity scrub tower in the industry
Media
Frames from Alloway's own demo film; swapped for new photos as they arrive.
More harvesters in the fieldCompare
Check any machines in this family and line them up.
| Rigid Harvester | Folding Harvester | |
|---|---|---|
| Rows | 6R22 to 8R22 | 12 at 22-inch spacing |
| Empty weight | 18,700 to 20,000 lbs | — |
| Gearbox | 200 hp | 250 hp |
| Elevator | 42 in curved parabolic | — |
| Tank | — | 3.5 ton |
| Transport width | — | 17' 8" folded |
Rigid Harvester
Folding Harvester
Rows
6R22 to 8R22
12 at 22-inch spacing
Empty weight
18,700 to 20,000 lbs
—
Gearbox
200 hp
250 hp
Elevator
42 in curved parabolic
—
Tank
—
3.5 ton
Transport width
—
17' 8" folded
Request a quote
Put it to work this fall
Every Alloway machine is sold and serviced through our dealer network. Call us or your nearest dealer for pricing, availability and trade options.
Requesting a quote for: Folding Harvester
